Ubiquiti airFibre 60 GHz Point-to-Point (PtP) Radio System 1.8 GBps Throughput 12km Range

AF60LR
K2,119.99 inc GST
Please send any quote requests through the Contact Us page
In Stock Low Stock Out Of Stock Please See Attributes
Qty Each (inc GST) Each Save %
Features
  • Up to 1.8 Gbps Throughput: Lightning-fast data speeds
  • Up to 12 km Range: Connects distant locations
  • Low Interference 60 GHz Band: Stable and reliable connections
  • Automatic Channel Width Switching: Optimizes performance in varying conditions
  • True Duplex Gigabit: Efficient two-way data flow
  • Built-In Bluetooth Management (UISP™ App): Easy setup and management
  • High-Gain Dish Antenna: Strong, focused signals
  • Passive PoE: Simple single-cable power and data
  • Robust Outdoor Design: Durable for PNG environments
  • GPS Synchronization: Enhances network stability
  • Intuitive airOS®: Powerful management interface
  • Point-to-Point (PtP) Optimized: Ideal for wireless bridging
  • Ideal for: Remote offices, last-mile internet, WISP backhaul, surveillance, disaster recovery

Order online! Apply for an online business account.


Product Description

High-Speed, Long-Range Wireless Connectivity for Papua New Guinea: Ubiquiti airFiber 60 GHz Radio System (1.8 Gbps, 12km)

Revolutionize your network infrastructure in Papua New Guinea with the Ubiquiti airFiber 60 GHz Radio System (AF60). This advanced 60 GHz radio delivers low-interference and ultra-high-throughput connectivity, achieving speeds of up to 1.8 Gbps. Integrated with a high-gain dish antenna, the AF60 provides reliable connections over distances of up to 12 kilometres, making it ideal for bridging long distances and providing high-speed internet access across Papua New Guinea.

Experience true duplex Gigabit performance, ensuring efficient and simultaneous data transmission and reception. The AF60 intelligently supports two-channel width options – 2 GHz and 1 GHz – automatically switching between them to optimize link performance based on environmental conditions in Papua New Guinea.

Setting up and managing the AF60 is simplified with built-in Bluetooth management, allowing for easy configuration via the UISP™ App. This feature streamlines deployment and ongoing maintenance, saving you time and resources in Papua New Guinea.

Key Benefits for Businesses and ISPs in Papua New Guinea:

  • Ultra-High Throughput (Up to 1.8 Gbps): Deliver lightning-fast internet speeds and handle bandwidth-intensive applications.
  • Long Range Connectivity (Up to 12 km): Connect remote locations and bridge significant distances across Papua New Guinea.
  • Low Interference 60 GHz Band: Operate in a less congested spectrum for stable and reliable connections.
  • Automatic Channel Width Switching: Optimizes link performance by adapting to changing conditions.
  • True Duplex Gigabit Performance: Ensures efficient bi-directional data flow.
  • Built-In Bluetooth Management: Simplifies setup and management via the UISP™ App.
  • High-Gain Dish Antenna: Provides strong and focused signals for long-range links.
  • Passive PoE Power: Simplifies installation with single-cable power and data.
  • Robust Design: Built with durable aluminium and UV-stabilized polycarbonate for outdoor deployments in Papua New Guinea.
  • GPS Synchronization: Enhances network stability and performance.
  • airOS® Operating System: Intuitive and powerful management interface.
  • PtP Only Mode: Optimized for point-to-point wireless bridging.

Ideal Applications in Papua New Guinea:

  • Connecting Remote Offices and Branches: Establish high-speed links between geographically separated locations.
  • Last-Mile Internet Service Provision: Deliver Gigabit internet to underserved areas.
  • Backhauling for Wireless ISPs (WISPs): Create high-capacity backhaul links for your network infrastructure.
  • Surveillance and Security Networks: Transmit high-resolution video feeds over long distances.
  • Disaster Recovery and Temporary Connectivity: Quickly establish reliable communication links in emergencies.

Technical Specifications:

  • Maximum Throughput: 1.8 Gbps
  • Maximum Range: 12 km
  • Operating Frequency: 57 to 71 GHz (subject to regulatory region in PNG)
  • Channel Bandwidth: 2160, 1080 MHz
  • GPS: Yes
  • Networking Interface: 10/100/1000 Mbps RJ45 Ethernet
  • Power Method: Passive PoE (48VDC, 0.65A Gigabit PoE Adapter included)
  • Maximum Power Consumption: 18W
  • Operating Temperature: -40 to 60° C (-40 to 140° F)
  • Management Interface: Bluetooth management via UISP™ App, WEB UI
  • Encryption: WPA2-PSK (AES)
  • Dimensions (Antenna): Ø413 x 360 mm (Ø16.3 x 14.2")
  • Weight (with Mount): 2.7 kg (6 lb)

Deploy high-performance, long-range wireless connectivity across Papua New Guinea with the Ubiquiti airFiber 60 GHz Radio System. Contact us today for more information and pricing!

  • Maximum Throughput: 1.8 Gbps
  • Maximum Range: 12 km
  • Operating Frequency: 57 to 71 GHz (subject to regulatory region in PNG)
  • Channel Bandwidth: 2160, 1080 MHz (automatic switching)
  • GPS: Yes
  • Networking Interface: 10/100/1000 Mbps RJ45 Ethernet
  • Power Method: Passive PoE (48VDC, 0.65A Gigabit PoE Adapter included)
  • Maximum Power Consumption: 18W
  • Operating Temperature: -40 to 60° C (-40 to 140° F)
  • Management Interface: Bluetooth management via UISP™ App, WEB UI
  • Encryption: WPA2-PSK (AES)
  • Dimensions (Antenna): Ø413 x 360 mm (Ø16.3 x 14.2")
  • Weight (with Mount): 2.7 kg (6 lb)

Key Benefits for Businesses and ISPs in Papua New Guinea:

  • Ultra-High Throughput (Up to 1.8 Gbps)
  • Long Range Connectivity (Up to 12 km)
  • Low Interference 60 GHz Band
  • Automatic Channel Width Switching for optimized performance
  • True Duplex Gigabit Performance
  • Built-In Bluetooth Management via UISP™ App for easy setup
  • High-Gain Dish Antenna for strong, focused signals
  • Passive PoE Power for simplified installation
  • Robust Design with durable materials for outdoor deployments
  • GPS Synchronization for enhanced network stability
  • airOS® Operating System with an intuitive management interface
  • PtP Only Mode optimized for point-to-point bridging

Ideal Applications in Papua New Guinea:

  • Connecting Remote Offices and Branches
  • Last-Mile Internet Service Provision
  • Backhauling for Wireless ISPs (WISPs)
  • Surveillance and Security Networks
  • Disaster Recovery and Temporary Connectivity
Technical Specifications
Brand Ubiquiti
Product Type Point-to-Point (PtP) Radio System
Colour White
Dimensions Ø413mm X 360mm
Processor Quad-Core ARM Cortex A7
RAM 256MB DDR3
Wattage 18W
Weight Without Mount: 1.5kg
Channel Bandwidth 2160, 1080 Mhz
GPS Yes
Maximum Range 12 km
Maximum Throughput 1.8 Gbps
Operating Frequency 57GHz to 71 GHz
